RFID Card Rader

Bluetooth card reader

Item	Specifications
Model	R58B/R58C/R58D
Frequency	125KHZ/13.56MHz
Card Type	S50/S70/Ntag203/Ntag213
Decode Capability:	1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, China post etc. 2D: QR Code, Data Matrix, etc
Communication	Bluetooth/2.4G
Format	Default 8-bit hex system (format customizable, like 10-bit 10 system/10-bit hex system etc)
Distance	20mm-60mm（depend on card type）
Reading Rate	106K/Bit
Reading Speed	0.1S
Reading Interval	0.5S
Reading Time	＜100mS
Working Temperature	-20℃—70℃
Working Current	100mA
Charge Voltage	5V
Dimensions	（product）/142mm×90mm×61mm（package）
Weight	50G（product）/150G（package）
Operating System	IOS, Win 7\Win 10\Android, etc
Others	Status indicator: 4-colors LED (white :connection status, red :scan confirmation, blue: indicator, green:power Built-in buzzer
